Download display files

Download the file(s) you plan to use into My Documents and the folder called Magic Contest Documents\Display.

The below examples are categorized as 2=pair, 4=team or 1=individual. A report designed for pair contests normally works for individual contests.

2 Starting list Seating in round 1, player names, club
…, 18 pairs per page, 1024×768 projector
…, 24 pairs per page, 1024×768 projector
…, 30 pairs per page, 1024×768 projector
2 Ranking Rank, pair number, score, percentage, name
…, 18 pairs per page, 1024×768 projector
…, 24 pairs per page, 1024×768 projector
…, but score and percentage to the right
2 Top-5 Top-5 and ranking, 5+12 pairs per page
2 Score recap Round winner, top-5, ranking, no scores, 1024×768
2 Score recap Round winner, ranking (only first 15 pairs, one page), hand, frequencies, 1024×768
…, frequencies with percentages
…, score table with all contracts
2 Swedish strata Round winner, ranking (top-14, strata order), two hands per page, frequencies (two columns), 1024×768
…, Swedish Bridge Festival, side event, semi-barometer, top-23
2 Swiss pairs Round winner, top-5, seating in a grid, frequencies
2 Score recap Three projectors, two boards per round, round winner, top-15, hand, frequency
4 Starting list Seating in round 1, team name, roster
4 Match Table, teams, IMPs, VPs, rank, total VPs, seating in next round
2 (4) Butler in team event Two displays, one for the latest round and another for the cumulative butler
4 Swiss teams Scenario with one round delay, show only finished matches, keep correct seating on the screen, 1024×768
…, round 5 is in progress, show finished matches or number of comparisons, show seating in round 6
…, round 5 has finished, all matches are complete, wait with draw for round 7, keep round 6 seating so the teams move to the right table
…, round 6 has started, make draw for round 7, show ranking after round 5, show seating in round 7

The original download page is found here: brenning.se/mcerdisplay.asp

.

2 … Starting list … Seating in round 1, player names, club

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: StartingList
Top of page

.

2 … Starting list … Seating in round 1, player names, club, 18 pairs per page, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: StartingList
Tags: FirstRow, NumRows, RepeatRows
Same as previous, but optimised for 18 pairs on a 1024×768 projector.

When the first 18 pairs have shown for a certain period of time, the next 18 pairs are shown, and so on.

Top of page

.

2 … Starting list … Seating in round 1, player names, club, 24 pairs per page, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: StartingList
Tags: FirstRow, NumRows, RepeatRows
Same as previous, but optimised for 24 pairs on a 1024×768 projector.
Top of page

.

2 … Starting list … Seating in round 1, player names, club, 30 pairs per page, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: StartingList
Tags: FirstRow, NumRows, RepeatRows
Same as previous, but optimised for 30 pairs on a 1024×768 projector.
Top of page

.

2 … Ranking … Rank, pair number, score, percentage, name

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: Ranking
Tags: HideFields
Top of page

.

2 … Ranking … Rank, pair number, name, score, percentage, 18 pairs per page, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: Ranking
Tags: FirstRow, NumRows, RepeatRows
Same as previous, but optimised for 18 pairs on a 1024×768 projector.

When the first 18 pairs have shown for a certain period of time, the next 18 pairs are shown, and so on.

Top of page

.

2 … Ranking … Rank, pair number, name, score, percentage, 24 pairs per page, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: Ranking
Tags: FirstRow, NumRows, RepeatRows
Same as previous, but optimised for 24 pairs on a 1024×768 projector.
Top of page

.

2 … Ranking … Rank, pair number, name, score, percentage

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Block: Ranking
Tags: ShowFields, WidthFields
Top of page

.

2 … Top-5 and ranking … Two blocks, one with always top-5, the other with next 12 pairs

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: TopN, Ranking
Tags: FlipTime, HideFields, FirstRow, NumRows, RepeatRows
The top-5 pairs are fixed at the top of the page. Below, the next 12 pairs keep changing every 12 seconds, which is a little bit faster than the default 15 seconds in the Current standing settings.
Top of page

.

2 … Score recap … Round winner, top-5, ranking, no scores, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: RoundWinner, TopN, Ranking
Tags: FirstRow, NumRows, RepeatRows
The top-3 pairs in the round are fixed at the top of the page. Below, the top-5 ranked pairs show. Below that, the next 15 pairs keep changing.
Top of page

.

2 … Score recap … Round winner, ranking (only first 15 pairs, one page), hand, frequencies, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: RoundWinner, Ranking, Column, Hand, Frequency
Tags: FirstRow, NumRows
The top-3 pairs in the round are fixed at the top of the first page. Below, the top-15 ranked pairs show.

On the next pages, hands and frequencies with scores are shown.

Top of page

.

2 … Score recap … Round winner, ranking (only first 15 pairs, one page), hand, frequencies with percentages, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: RoundWinner, Ranking, Column, Hand, FrequencyPercentage
Tags: FirstRow, NumRows
The top-3 pairs in the round are fixed at the top of the first page. Below, the top-15 ranked pairs show.

On the next pages, hands and frequencies with scores and percentages are shown.

Top of page

.

2 … Score recap … Round winner, ranking (only first 15 pairs, one page), hand, score table with all contracts, 1024×768 projector

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: RoundWinner, Ranking, Columns, Hand, ScoreTable
Tags: FirstRow, NumRows
The top-3 pairs in the round are fixed at the top of the first page. Below, the top-15 ranked pairs show.

On the next pages, score tables with all contracts and scores are shown.

Top of page

.

2 … Swedish strata … Round winner, ranking (top-14, strata order), two hands per page, frequencies (two columns), 1024×768 projector

Version 4.13 (August 2018)

Download: Green
Example: Preview
Blocks: RoundWinner, Ranking, Columns, Hand, Frequency
Tags: AutoTitle1, FirstRow, NumRows, ShowFields, WidthFields, SortFields, ShowOneBoardOnly
Round winner and top-14 pairs show on the first page. Swedish strata is shown in the leftmost column.

On the next page, two hands plus frequencies are shown. The frequencies are shown in two columns to allow for many different results.

Top of page

.

2 … Swedish strata … Ranking (top-23, strata order), two hands per page, frequencies (two columns), Swedish Bridge Festival, side event, semi-barometer, 1024×768 projector

Version 4.13 (August 2018)

Download: Green
Example: Preview
Blocks: Ranking, Columns, Hand, Frequency
Tags: AutoTitle1, FirstRow, NumRows, ShowFields, WidthFields, SortFields, ShowOneBoardOnly
The top-23 pairs show on the first page. Swedish strata is shown in the leftmost column.

On the next pages, two hands plus frequencies are shown on each page. The frequencies are shown in two columns to allow for many different results.

Top of page

.

2 … Score recap … Round winner, top-5, seating in a grid, frequencies

Download: Green Brown Blue Black SWAN
Example: Preview Preview Preview Preview Preview
Blocks: RoundWinner, TopN, Columns, SwissColumn, Hand, Frequency
Tags: FirstRow, NumRows
The top-3 pairs in the round are fixed at the top of the first page. Below, the top-5 ranked pairs show.

Further down on the first page, the seating assignments are shown in a grid, only containing pair number, rank, percentage and next seating. This list is sorted by pair number so the pairs can easily find their seating assignments for the next round.

On the next pages, hands and frequencies with scores are shown.

Just to clarify, the previous score recaps work fine also in Swiss pairs. Next round is automatically shown in case of Swiss pairs.

Top of page

.

2 … Score recap … Three projectors, two boards per round, round winner, top-15, hand, frequency

Download: Green
Blocks: RoundWinner, Ranking, Columns, Hand, Frequency
Tags: FileNameLetter, FirstRow, NumRows, ShowOneBoardOnly, INCLUDE_FILE
A Swedish club owns three projectors. When they play two boards per round, it is possible to use all projectors without having to change displays (except between rounds) in the following way:

Projector 1: Round winner and top-15
Projector 2: First board in the round
Projector 3: Second board in the round

Top of page

.

4 … Starting list … Seating in round 1, team name, roster

Download: Green Blue Brown Black SWAN
Example: Preview
Block: StartingList
Top of page

.

4 … Match … Table, teams, IMPs, VPs, rank, total VPs, seating in next round

Download: Green Blue Brown Black SWAN
Example: Preview Preview Preview Preview Preview
Block: Match
The version 4.12 news list specifies that the Current standing settings must be the following for the Match block to work properly:
Top of page

.

2 (4) … Butler in team event … Two displays, one for the latest round and another for the cumulative butler

Download: Green
Example: Preview TV1
(butler for one round)
Preview TV2
(cumulative butler)
Blocks: IAF, ScoreTable, Ranking
Tags: INCLUDE_FILE, Columns, ShowOneBoardOnly
Note: You cannot use the zip file as is. You must first extract the files into the Magic Contest Documents\Display folder. See more below.
Two TV:s are used during the Swedish Premier League to display the butler. One shows the latest round while the other shows the cumulative butler.

The image is shown on an HD-TV in portrait mode (1200×1900). This is thanks to using a miniature computer called Raspberry Pi that can be set to output such a signal.

The round display uses ShowOneBoardOnly to show two boards per page (sounds contradictory, I know 🙂 , but look inside the downloaded files to see how it is done). Several INCLUDE_FILE:s are used to keep the display codes to a minimum.

The cumulative display shows one column with the top 50 pairs in regular text size. The next 20 are shown in a smaller text size in two columns at the bottom of the page.

As opposed to other download files on this page, all files inside this compressed file, both .mcy and .inc, must be manually extracted into the Magic Contest Documents\Display folder. This is because the compressed file contains one .mcy file for the round (ending with “round”), and another for the butler (ending with “point league”), and they are used separately by the pair window for the round and the point league for the cumulative butler.

The document Display and Butler (point league) contains the necessary documentation on the topic.

Top of page

.

4 … Swiss teams … Scenario with one round delay, show only finished matches, keep correct seating on the screen, 1024×768 projector

Version 4.13 (August 2018)

The below displays work this way:

  1. The selected movement is 2 random rounds. After that there is a one round delay, so the round 1 ranking decides the round 3 seating, and so on.
  2. See Match above for necessary settings to only show finished matches.
  3. Skip a few rounds…
  4. Play starts in round 5. As long as no matches have finished the previous display is still shown on the screen.
  5. As soon as one match in round 5 has finished, all matches are shown. IMPs, VPs, Rank and Total VPs are only shown for matches that have finished.
  6. When all matches have finished and Magic Contest asks you to make the draw for the next round, do nothing. Keep round 5 matches and round 6 seating on the projector. It is important that the teams are seated before the new seating is created and shown on the screen.
  7. Now it is time to start the Bridgemate database for round 6.
    1. Activate round 6
    2. Create the Bridgemate database
    3. Activate round 5 (in order to make the draw and change the projectors)
  8. For the scenario to work, i.e. change from match+match on the two projectors to instead show ranking on one and all matches on the other, you now need to manually change Contest menu > Settings > Display > Score recap to the display that contains the ranking.
  9. Once the teams are seated you can make the draw and show the new seating. The easiest way to do this might come across as a little peculiar, but it works:
    1. Move to one of the team IMP results.
    2. Use the Delete button on the keyboard to delete the result.
    3. Move to another result to ensure that the result is really deleted.
    4. Check the Bridgemate checkbox to import results. You will again get the question to make the draw for round 7. Do this, and then watch how the match+match displays change into ranking+match.
    5. The reason this works is that Magic Contest only creates the draw and the displays if any results have changed. By deleting a result you ensure that the end-of-round-trigger is activated.
  10. Now you can manually change Contest menu > Settings > Display > Score recap back to the original display, and wait for a match to finish in round 6 to change from ranking+match to match+match.
Top of page

.

4 … Swiss teams … Round 5 is in progress, show finished matches or number of comparisons, show seating in round 6

Version 4.13 (August 2018)

Download: Green
Example: Preview Match 1-13 Preview Match 14-25
Blocks: Match
50 teams, 25 matches, one BYE, matches 1-13 on one projector, matches 14-25 on another.
Top of page

.

4 … Swiss teams … Round 5 has finished, all matches are complete, wait with draw for round 7, keep round 6 seating so the teams move to the right table

Version 4.13 (August 2018)

Download: Same as above
Example: Preview Match 1-13 Preview Match 14-25
Blocks: Match
50 teams, 25 matches, one BYE, matches 1-13 on one projector, matches 14-25 on another.
Top of page

.

4 … Swiss teams … Round 6 has started, make draw for round 7, show ranking after round 5, show seating in round 7

Version 4.13 (August 2018)

Download: Green
Example: Preview Ranking Preview Match 1-13/14-25
Blocks: Ranking, Match
50 teams, 25 matches, one BYE, top-22 ranking with roster on one projector, matches 1-13 alternating with 14-25 on another.
Top of page

.
